 Conveyor length 2meters, with Auto Feeder
(Defending Product)
Speed 30 to 450 packets per minute,
Packing Style : Centre Seal
Film thickness 40 microns and above
Packing Material All Type of laminated B.O.P.P,LD Poliester,
Aluminium Foil etc.,
Packing Size Length : 30mm to 200mm, Width : 30mm to
150mm,
Heigh t: 10 mm to 70mm
Multi axis motion Control System with 10 MBPS
Speed Power:7KVA
Dimension : length : 3700mm, width : 1200mm,
height : 1800mm, Weight approx 800 to 1000kg |
Cantilever construction that provides for easy cleaning and
maintenance, with easy access to mechanical and
electrical components
Left to right operating direction
Rotary cross sealing jaws with an electronic overload
safety switch
Self-centering film reel holder with a operated
brake system
In feed conveyor 2000mm long
Adjustable film folding box
7.0” HMI 65K Color Display with numeric keyboard and 1MB
Storage capability, provides ease in setting machine
parameters, it displays operational and error messages
The control allows data storage for multi different
machine set-ups
Individual heater controls are used for easily find the
heater conditions
Automatic paper product correction and avoiding
empty packets
Providing intelligence operating system for auto
position accuracy |
